Product Summary
The SKKH500-16E is a Thyristor/Diode Module. The applications of the SKKH500-16E are AC motor softstarters, input converters for AC inverter drives, DC motor control, temperature control, professional light dimming.
Parametrics
SKKH500-16E general specifications: (1)VT:max.1.5V; (2)VT(TO):max.0.925V; (3)I2T:max.0.27mΩ; (4)IDD;IRD:max.100mA; (5)tgd:1us; (6)tgr:2us; (7)(di/dt)cr:max.200A/us; (8)(dv/dt)cr:max.1000V/us; (9)VGT:min.3V; (10)IGT:min.200mA; (11)VGD:max.0.25V; (12)IGD:max.10mA.
Features
SKKH500-16E features: (1)heat transfer through aluminium nitride ceramic isolated metal baseplate; (2)precious metal pressure contacts for high reliability; (3)UL recognized, file no. E63532.
Diagrams
 |
